FLOWMATIC NOZZLE WITH TRIGGER TRIGGERFLOW REGULAR

Trigger_nozzle_TRIGGERFLOW_with_handle_face_compact
Trigger_nozzle_TRIGGERFLOW_without_handle_back_compact
Trigger_nozzle_TRIGGERFLOW_without_handle_face_compact
Trigger_nozzle_TRIGGERFLOW_with_handle_back_compact

NOT FOR SALE IN THE USA

  • ENHANCED ERGONOMICS
    Natural position of hands, which facilitates the control of the nozzle and its movements.
  • INTUITIVE
    Progressive opening and closing of the slide valve through a large trigger.
  • DOUBLE JET FLASH OVER
    Double Jet Flash Over at different angles to operate at a short or long distance.
  • ENHANCED SECURITY
    Automatic closing of the nozzle in case of a fall during its use, and protection of the hand and the trigger by a large sized removable bridge.

Features

  • Trigger_nozzle_TRIGGERFLOW_with_handle_face_compact

PRODUCT CHARACTERISTICS

NOT FOR SALE IN THE USA

Ideal for Pulsing, TRIGGERFLOW Regular nozzle brings a revolution to the firefighting area. Its design makes it safer, more intuitive and more ergonomic.

One hand holds the nozzle and controls the flow rate with the fingertips, and the other hand manages the jet pattern and will withstand the recoil force if necessary. A complete control of the nozzle without the need to move the hands!

LEADER TRIGGERFLOW – REGULAR NOZZLE WITH TRIGGER

TRIGGERFLOW nozzle with large trigger is a revolution in the field of fire fighting. It allows to control the flow rate with the fingertips!


Data Sheet

Type Automatic
WEIGHT 5.4 Lbs
AVAILABLE MODELS See Image Below
DIMENSIONS W X D X H 1.5’’ = 13″ x 4″ x 8.6″
2’’ = 13″ x 4″ x 8.6″
PRESSURE 100 psi
AVAILABLE INLETS See Image Below
MATERIAL Hard anodized aluminum
Size Regular
VALVE stainless steel slide valve
BUMPER polyurethane
NOMINAL PRESSURE 230 PSI
SPECIAL FEATURES Flow rate control by the trigger and double jet for attack

LEADER TRIGGER NOZZLE

Downloads

Cutsheet PDF Product Manual PDF
